RF30000 M22/M24 Micro Nano Bubble Faucet Aerator with H59-1 Brass Construction and Multi-Layer Stainless-Steel Screen
Product Overview
RF30000 is a compact faucet aerator designed for M22 and M24 tap connections. It combines an H59-1 brass body with SUS304 internal components and a multi-layer stainless-steel screen structure. The unit is intended for municipal tap-water outlets within the specified operating pressure and temperature range.
Its compact body can be integrated into compatible kitchen, bathroom, utility-room, and wash-basin faucets. The internal mesh structure is designed to help retain larger visible particles before water reaches the outlet. It should be used as a faucet accessory, not as a replacement for a dedicated drinking-water purifier or fine filtration system.
Product Specifications
| Item |
Specification |
| Compatible Thread |
M22 / M24 |
| Applicable Water Source |
Municipal tap water |
| Operating Pressure |
0.15–0.6 MPa |
| Operating Temperature |
+5°C to +70°C |
| Main Body Material |
H59-1 brass |
| Valve Core Material |
SUS304 stainless steel |
| Screen Configuration |
Dual-layer stainless-steel filter gasket plus six-layer stainless-steel mesh |
| Filtration Rating |
380 μm |
| Technology |
Gas-liquid cutting technology |
| Dimensions |
27 × 27 × 36 mm |
| Unit Weight |
0.117 kg |
| Package Dimensions |
122 × 122 × 35 mm |
| Package Weight |
0.292 kg |
Working Principle
Water flows through the aerator’s internal passage and multi-layer stainless-steel mesh assembly. The structural design uses gas-liquid cutting technology at the faucet outlet. The screen components provide a coarse barrier for larger particles that may be present in the water path.
Performance can vary with local pressure, faucet design, water quality, and installation condition. This product is not intended to reduce dissolved minerals, remove microorganisms, or replace a certified water-treatment system.
Key Features
Compact M22/M24 Faucet Compatibility
Designed for commonly used M22 and M24 faucet connections, helping distributors and fixture brands build a compact faucet-accessory offering.
Brass and Stainless-Steel Construction
The main fitting uses H59-1 brass, while the valve-core material is SUS304 stainless steel. Material selection supports a durable accessory structure for compatible municipal-water applications.
Multi-Layer Screen Design
A two-layer stainless-steel filter gasket and six-layer stainless-steel mesh are included in the structure. The stated 380 μm rating is suitable for retaining larger debris, not for fine purification.
Suitable Operating Range
RF30000 is specified for 0.15–0.6 MPa operating water pressure and +5°C to +70°C water temperature. Confirm actual installation conditions before selection.
Easy Faucet Upgrade
The compact 27 × 27 × 36 mm format is suited to faucet accessory programs, replacement-part ranges, private-label projects, and small-space installations.
Application Scenarios
Why Choose BriskSpring
BriskSpring develops water-related accessories and treatment products for residential and commercial applications. We support product selection, OEM branding, packaging customization, and technical-document review according to the confirmed model and destination market.
For an accurate recommendation, please share the faucet thread standard, application, local pressure range, target market, quantity, and packaging requirements.
FAQ
Is RF30000 a water purifier?
No. RF30000 is a faucet aerator with a coarse stainless-steel screen structure. It is not an RO system, microbiological purifier, or replacement for a dedicated drinking-water filter.
What faucet threads are compatible?
The listed connection options are M22 and M24. Buyers should verify the faucet thread type and dimensions before ordering.
What is the screen rating?
The filter screen gasket is listed at 380 μm. It is intended for larger visible particles rather than fine water purification.
Can it be used with hot water?
The listed applicable water-temperature range is +5°C to +70°C. Confirm the actual faucet and plumbing conditions before installation.
What water pressure is suitable?
RF30000 is specified for 0.15–0.6 MPa operating pressure.
Can the product be customized?
Logo, retail packaging, instructions, and order configuration can be evaluated based on order quantity and the confirmed project requirements.
